DT320 Mini Pipe Crawler
Inspect pipes from 6″ to 12″ in diameter
DT320 Packages
DT320 Mini Base Package
Pipe size: 6"-12" (152mm-305) center
Equipped with 200M tether length, counter reel, 5.6" LCD controller, pipe range; undersized 6" to 12", pan tilt camera, manual elevating arm, lifting device and wheeled case.
DT320 Mini Crawler XL
Pipe size: 6"-12" (152mm-305) center
Equipped with the DT320 Mini Lite plus powered reel, control console, all wheeled and track options.
DT320 Mini Base Package
Pipe size: 6"-12" (152mm-305) center
Equipped with 200M tether length, counter reel, 5.6" LCD controller, pipe range; undersized 6" to 12", pan tilt camera, manual elevating arm, lifting device and wheeled case.
Rugged and Durable Design
Utilizing tough materials including anodized aluminum and stainless steel components and sapphire for the camera lens cover, the DT320 is built to withstand the punishment that trenchless technology is inevitably subjected to.
Cast aluminum and stainless steel frame
Sapphire glass camera lens cover
Steerable
Clean sheet engineering
Pipe Crawler Add-Ons
In a single day of inspection work, you may come across various pipe profiles. This is why we have developed modular pipe crawlers with plug-and-play technology, including pipe inspection cameras and various wheel options.
Portable, battery operated mini pipe crawler
The DT320 Mini Pipe crawler is designed with portability in mind. Allowing operators to conduct storm and wastewater inspections without the need for topside power.
Battery Powered - Deep Trekker crawlers and control units are powered by long lasting lithium ion batteries, everything you need to perform an inspection can fit into one or two wheeled cases.
At a glance
No topside power or boxes required
Software integrations
Fully submersible
Pan & tilt HD camera
1000lbs break strength
Steerable
Wheel and track options
All in one control system
Easy to operate
The DT320 Mini Crawler is easy to operate with the use of its handheld control console. Effortlessly create a visual catalog of your inspections and integrate directly with asset-management software.
Customized for the job
The DT320 Mini crawler can be equipped with various wheel options and tracks so that you can tailor the camera for the project at hand.
Compatible with the DT340
Complete your set of CCTV pipe crawlers. Both the DT340 and the DT320 Mini can operate using the same tether and control console.
Have a unique job? Let us help customize a crawler for you.
Completely Submersible
The DT320 utilizes an innovative magnetically coupled drive system for the wheels, which means that the crawler is completely waterproof and does not require ongoing maintenance. Many other crawler systems require regular gasket replacement or nitrogen gas filling to maintain their ability to keep water out.
Completely Submersible
The DT320 utilizes an innovative magnetically coupled drive system for the wheels, which means that the crawler is completely waterproof and does not require ongoing maintenance. Many other crawler systems require regular gasket replacement or nitrogen gas filling to maintain their ability to keep water out.
All purpose controller
Pipe inspections made easy. Operate the DT340 or DT320 Mini with its splash-proof controller. The easy to use control system reduces the learning curve for beginner operators.
Record your own video inspections or integrate with reporting software using the crawler’s standard video out port.
Weatherproof handheld controller
Record video inspections with voice over via DVR
All purpose controller
Pipe inspections made easy. Operate the DT340 or DT320 Mini with its splash-proof controller. The easy to use control system reduces the learning curve for beginner operators.
Record your own video inspections or integrate with reporting software using the crawler’s standard video out port.
Weatherproof handheld controller
Record video inspections with voice over via DVR
Comparing Deep Trekker Crawlers
Custom Quote
I would highly recommend the DT340 Crawler! the City of Hot Springs Arkansas Stormwater Division purchased the unit in 2017 and have inspected thousands of feet of stormwater sewer pipe with no issues. The battery operated unit provides plenty of power to inspect pipe for hours and is very mobile with no need for a generator or van to transport the unit. You won't regret the decision to purchase this unit. Feel free to contact me if you have any questions.
Dan Carder
City of Hot Springs Arkansas Stormwater Division
Best customer service experience I have ever experienced. These guys products work beyond compare and they will help you in any way possible with any question you have. Blew my mind when the owner of the company actually called me himself and has emailed me several times to assist with questions. We just started using them but we will be changing our entire fleet to Deep Trekker due to their superb products and the fact that you know you are dealing with a company that actually cares and wants to do everything they can to help their customers. Outstanding company.
David Haire
Pittsburg Tank & Tower
Our team have worked with Deep Trekker for several years and have found them to be the best supplier we have ever dealt with. The technology is market and industry leading and the after sales support is simply amazing. Professionally I have never encountered a company that treats its customers so well.
Mike Larkin
Fulcrum Robotics
DT320 Pipe Crawler Spec Highlights
DT320 Mini Crawler General Specifications
| Width: | 123 mm (5”) |
| Height: | 87 mm (4”) |
| Length: | 440 mm- 630 mm (17” - 25”) |
| Weight: | 11 kg (25 lb) - 16 kg (35 lb) |
| Depth Rating: | 50 m (124 ft) |
| Body Material: | Stainless Steel, Aluminium |
| Window: | Sapphire Glass Lens Cover Wiper |
| Turn Radius: | 0 mm (0”) |
| Speed: | 12 m / Min |
| Operating Temp: | -5C To 40C (23F - 104F) |
| Software compatibility: | Integrates with most sewer inspection software |
| Warranty: | 1 Year - Parts And Labor (2-3 years optional) |
Electrical System
| System: | 19.2 Vdc (Lithium Batteries) |
| Sensors: | Incline, Roll, Leak, Camera Pan/Tilt |
| Lighting: | 650 Lumens |
| Camera: | 700Hd Tvl, Color, 0.001 Lux (Low Light), Controller Controlled, Pan (360 degree) & Tilt (280 degree) |
| Wheel/Drive: | Skid Steer - 4Wd With Track Belt |
| Sonde: | 512 Hz |
Deep Trekker reserves the right to amend these specifications at any time without notice
