At a glance
No topside power or boxes required
Portable and compact carrying cases
GIS and WinCan integrations
Fully waterproof system
PTZ HD camera
Wheel and track options
All-in-one control system
Optional Powered Reel
Leave the CCTV truck behind
Built for municipal pipe inspections as small as 8” (203 mm) in diameter, the DT340 Pipe Crawler is fully submersible. Being battery operated removes the need for a CCTV truck, generator or onsite power supply.
Operate the DT340 Pipe Crawler with its easy to use handheld controller. View and record video, document inspections, and upload directly to an asset-management software.
DT340 Pipe Crawler Packages
DT340L Pipe Crawler Package
[Pipe size: 8" center]
The DT340 lite package includes everything you need to start out with pipe inspections. Including a static camera, easily steer and maneuver through your pipelines with the handheld video controller.
DT340S Pipe Crawler Package
[Pipe size: 8" - 12" center] The DT340S package includes everything you need as a professional pipe inspector. The system includes a pan, tilt and zoom camera to easily view your entire pipe system as well as a tether length counter to know where defects are found within the pipe system.Learn More
DT340X Pipe Crawler Package
[Pipe size: 8" - 36" center] This DT340X is packaged for larger diameter pipe inspections. The system includes an elevating arm for the pan, tilt and zoom camera and additional lights. The elevating arm brings the camera head to the center of a pipe as large as 36" (914 mm).Learn More
DT340 Pipe Crawler Spec Highlights
DT340 ‘S’ Crawler General Specifications
|Length:||710 mm (27.95”)|
|Width:||141 mm (5.55”)|
|Height:||151 mm (5.96”)|
|Weight:||16.6 kg (36.59 lb)|
|Materials:||Stainless Steel Aluminium, High Strength Sapphire|
|Depth Rating:||50 m (164 ft)|
|Viewing Capability:||Pipelines 200 mm (8”) Diameter To 900 mm (36”) Center|
|Wheel Sizes:||200 mm Diameter (8”) (Standard), 250 mm Diameter (10”) (Optional), 300 mm Diameter (12”) (Optional)|
|Turn Radius:||0 mm (0”)|
|Speed:||12 m / Min|
|Operating Temp:||-5C To 40C (23F - 104F)|
|Warranty:||1 Year - Parts And Labor|
|Optional:||Powered Reel, 200 m - 400 m|
I would highly recommend the DT340 Crawler! the City of Hot Springs Arkansas Stormwater Division purchased the unit in 2017 and have inspected thousands of feet of stormwater sewer pipe with no issues. The battery operated unit provides plenty of power to inspect pipe for hours and is very mobile with no need for a generator or van to transport the unit. You won't regret the decision to purchase this unit. Feel free to contact me if you have any questions.
City of Hot Springs Arkansas Stormwater Division
Portable for rapid response
Operate in remote locations and hard to access environments with the DT340 portable design, fitting in two wheeled Pelican cases for easy deployment.
Scalable design & assorted wheel options
The DT340 Pipe Crawler can be redesigned or upgraded to fit various pipe diameters. Interchange with various wheel options to inspect different pipe materials.
Designed to support tough jobs, the DT340 Pipe Crawler is made with anodized die-cast aluminum, stainless steel and a sapphire glass camera lens.
Its magnetically coupled wheel drivers requires low maintenance; no need to replace or grease.
Cast aluminum and stainless steel frame
Sapphire glass camera lens cover
Clean sheet engineering
All purpose controller
Pipe inspections made easy. Operate the DT340 or DT320 Mini with its splash-proof controller. The easy to use control system reduces the learning curve for beginner operators.
Record your own video inspections or integrate with reporting software using the crawler’s standard video out port.
Weatherproof handheld controller
Record video inspections with voice over via DVR
The DT320 Mini Crawler
Looking for a small pipe crawler to conduct CCTV sewer inspections in 6-inch pipes? The DT320 Mini Crawler is portable, efficient and easy to use. Topside power is not required; simply plug the tether in and deploy within minutes.
